ICU Electric Bed 5-Function 551 lb Load Quiet
$3,985.00 $4,195.00
Specifications
Model Number, YC-E5618K(I)
Safe Working Load (SWL), 551 pounds
External Dimensions (L x W), 84.6 inches x 41.3 inches
Mattress Platform (L x W), 76.8 inches x 32.7 inches
Height Adjustment Range (Min-Max), 18.1 inches - 28.3 inches
Back-rest Lifting Angle, 0 - 75 degrees
Knee-rest Lifting Angle, 0 - 45 degrees
Trendelenburg & Reverse Trendelenburg, 0 - 12 degrees
Motor System, 4 Linear Motors (Noise under 50dB)
Casters, 5-inch Central Locking System (TPR tire)
Platform Construction, Stamping ONE-TIME Forming Platform (Option for X-ray Resin Platform)
Included Accessories, Full SS IV Pole, 4 Drainage Hooks, ABS Side Rails & Headboard
Important Quality Control
* Easy to be cleaned and installed
* With UL/ROHS/EN Standard. Noise Under 50dB, With Lifetime 20,000Times Movement.
* Baosteel from Fortune Global 500
* Environmental plastic can be sterilized in 100°C,tensile upto 30MPa
* Solid bed base made of 5.0mm stamped rotating plate
* 11 Process epoxy painting, ASTM testing anti-baterial, paint thickness 0.12mm, brightness 60°, paint can resist 50kg impact
* Panasonic Robotic ensure 360° full smooth wedlding
Functions
5 Functions:
Reverse Trendelenburg
Accessories Details
* Stamping ONE -TIME forming platform, welded by robot to ensure smooth surface no welding scar, bearing 250KG load. Option ABS platform and resin X-ray translucent platform
* L-shaped foldable guardrail, made of bended tube, solid installing, 0 shaking, easy to clean, anti-pinch, protect patient's
safety
* Mordern design.Use new and strong inserted ABS fire-proof panel avoid off.
* Easy to be cleaned and installed.Net weight over 3.5kg.
* With bumper,protect the bed and patient during transportation
* TPR tire no worn out after running 30KM, save anti-winding hard shell, united forming without bolts
* Pass Dynamic test: Bearing 120kg run 30KM and pass obstacles 500time
* Castors with test report of BS EN 12530: 1998 standard
* Plastic drainage hook, movable
* Full SS IV pole, bearing 15kg
